Full DC Inverter
Cooling Capacity: 9,000 BTU/h
Applicable Area: 12–18 m²
Power Supply: 220–230V / 60Hz
Rated Power: 824 W
Rated Current: 4.50 A
Energy Rating: ★★★★★
CSPF: 4.92
EER: 10.92
Refrigerant: R32
Airflow(Hi/Mi/Lo): 550 / 400 / 320 m³/h
Indoor Noise(Hi/Mi/Lo): 40 / 34 /31 dB(A)
Outdoor Noise: 51.5 dB(A)
INSTALLATION
Liquid Pipe: Ø6.35 mm (¼")
Gas Pipe: Ø9.52 mm (⅜")
Max. Pipe Length: 25 m
Max. Level Difference: 10 m
Wall mounted / SPlit Type
Full DC Inverter
Cooling Capacity: 12,000 BTU/h
Applicable Area: 16–23 m²
Power Supply: 220–230V / 60Hz
Rated Power: 1,250 W
Rated Current: 5.09 A
Energy Rating: ★★★★★
CSPF: 4.94
EER: 9.60
Refrigerant: R32
Airflow (Hi/Mi/Lo): 560 / 420 / 350 m³/h
Indoor Noise (Hi/Mi/Lo): 31 / 29 /22 dB(A)
Outdoor Noise: 55 dB(A)
INSTALLATION
Liquid Pipe: Ø6.35 mm (¼")
Gas Pipe: Ø9.52 mm (⅜")
Max. Pipe Length: 25 m
Max. Level Difference: 10 m
Full DC Inverter
Cooling Capacity: 18,000 BTU/h
Applicable Area: 24–35 m²
Power Supply: 220–230V / 60Hz
Rated Power: 1,758 W
Rated Current: 7.64 A
Energy Rating: ★★★★★
CSPF: 4.86
EER: 10.24
Refrigerant: R32
Airflow (Hi/Mi/Lo): 891 / 635 / 550 m³/h
Indoor Noise (Hi/Mi/Lo): 45 / 39 / 33 dB(A)
Outdoor Noise: 56 dB(A)
INSTALLATION
Liquid Pipe: Ø6.35 mm (¼")
Gas Pipe: Ø12.7 mm (½")
Max. Pipe Length: 30 m
Max. Level Difference: 20 m
Full DC Inverter
Cooling Capacity: 22,000 BTU/h
Applicable Area: 29–43 m²
Power Supply: 220–230V / 60Hz
Rated Power: 2,149 W
Rated Current: 9.34 A
Energy Rating: ★★★★★
CSPF: 4.75
EER: 10.24
Refrigerant: R32
Airflow (Hi/Mi/Lo): 1,300 / 960 / 760 m³/h
Indoor Noise (Hi/Mi/Lo): 40 / 36.5 / 29 dB(A)
Outdoor Noise: 58 dB(A)
INSTALLATION
Liquid Pipe: Ø6.35 mm (¼")
Gas Pipe: Ø15.9 mm (⅝")
Max. Pipe Length: 30 m
Max. Level Difference: 20 m
Full DC Inverter
Cooling Capacity: 25,200 BTU/h
Applicable Area: 32–47 m²
Power Supply: 220–230V / 60Hz
Rated Power: 2,512 W
Rated Current: 10.90 A
Energy Rating: ★★★★★
CSPF: 4.41
EER: 10.03
Refrigerant: R32
Airflow (Hi/Mi/Lo): 1,300 / 960 / 760 m³/h
Indoor Noise (Hi/Mi/Lo): 40 / 36.5 / 29.5 dB(A)
Outdoor Noise: 59 dB(A)
INSTALLATION
Liquid Pipe: Ø6.35 mm (½")
Gas Pipe: Ø12.7 mm (¼")
Max. Pipe Length: 50 m
Max. Level Difference: 25 m
